Type:Long shank 2 flutes ball nose end mill
Material:Tungsten carbide
Hardness:HRC≤45°
Coating:TiAlCrN
2 Flutes long shank ball nose end mills for cutting all kinds of materials
Flutes No. | 2/4 Flutes |
Material | Tungsten carbide |
Coating | TiAlCrN |
Helix Angle | 35° |
Hardness | HRC45° |
Customized | Accept |
Smooth Finish | Highly polished |
Feature | Excellent chip evacuation |
Measurement | Metric |
Technology&Application
Incorporate latest molding, coating, edge preparation,and other manufacturing technology. Provide superior performance.
Coatings provide high-speed capability and are engineered from finishing to heavy roughing,The post-coat treatment reduces coating stresses, improves coating adhesion, minimises microchipping and edge build-up, and improves workpiece finish.Coated surface enable to get Longer tools life.
Application areas: Machining of cast iron, nonferrous alloy, chill cast iron, hard steel, stainless steel, plastic materials, fiberglass, carbon fiber and other non-metallic.
Served industries: Aerospace,Transportation,Medical Equipment,Military Manufacturing,Mold Development,etc.
Item No.: | Edge diameter | Edge length | Overall length | Shank diameter |
2F**R2*75S4 | 4 | 8 | 75 | 4 |
2F*R2.5*4*75S6 | 5 | 10 | 75 | 6 |
2F*R3*75 | 6 | 12 | 75 | 6 |
2F*R4*75 | 8 | 16 | 75 | 8 |
2F*R5*100 | 10 | 20 | 100 | 10 |
2F*R6*100 | 12 | 24 | 100 | 12 |
2F*R7*100 | 14 | 28 | 100 | 14 |
2F*R8*150 | 16 | 32 | 150 | 16 |
2F*R9*150 | 18 | 36 | 150 | 18 |
2F*R10*150 | 20 | 40 | 150 | 20 |
